The Ring Floodlight Camera is a connected security camera with floodlights built-in. With motion-activated recording and lighting, it’s meant to cover big yards and outdoor spaces. If you think there’s a problem, it has a built-in siren that you can regulate with the Ring app. Standard 1080p HD video resolution, two-way conversation with noise cancellation, programmable motion zones, and color night vision are also included. You have the option of a black or white finish. It’s identical to the Eufy Floodlight Camera and the Arlo Pro 3 Floodlight Camera, among other popular cameras.
The Ring Floodlight Camera is one of Ring’s most popular smart home products. Surveillance, motion-activated lighting, and a multitude of other functionalities are all handled by this lamp. It’s all about how you mount the Ring Floodlight Camera to get the most out of it.
The standard mounting is best for larger groups of people. Simply mount this light on just about any vertical surface and link it to an existing socket or any sort of connection. But what if you want to hang it from a soffit or a ceiling? Is that even possible?
On soffit vents, walls, and other similar surfaces, the Ring Floodlight Cam can be placed upside down. In fact, there are mounting options for this camera that do not obstruct its use in any manner. There have been a couple of techniques to installing this camera precisely where you can use it.
What is the Ring Floodlight Camera?
It is a flagship product from Ring, and it’s also one of their most expensive product.
The Ring Floodlight Cam is an all-in-one motion sensor light, home safety system, and alarm. The Ring app may be used to operate this Floodlight Cam, and Alexa can also be used to control it.
This floodlight cam is equipped with the kind of price tag that comes with any flagship gadget, which means that customers want to get the most bang for their buck.
Although this camera is designed to be installed upright on a wall, what if you wanted to install it upside down or on a sloped surface?
Let’s have a look at the many mounting options for this light.
How to Mount a Ring Floodlight Camera the Normal Way?
Before we start changing things up, let’s have a better understanding of how the Ring floodlight attaches.
A physical connection into your home is used to power this light.
This implies that it must be connected to a physical link.
Most external lighting connections will suffice for this light, but if you don’t have one that you’re willing to sacrifice, you’ll need to hire an electric professional to wire up your connection.
Then it’s only a time of following the instructions.
Mount the back bracket on the wall first, then connect it to the power source as follows:
The front cover/housing (which houses the light and camera) is then simply placed on top of this, and the hand screws are used to secure it:
The Ring floodlight includes with a mounting bracket and all of the components you’ll need to finish the installation right out of the box.
That’s helpful to know…
But what if you wish to hang this light from a horizontal or even upside-down exterior?
Mounting it Upside Down, on Angles, or on Slanted Surfaces
This lamp has established itself as Ring’s flagship product. Ring even confirmed this on Twitter: “It’s totally doable to mount this upside down with little to no complications along the way.”
Because the camera is on a ball attachment, and the lights can be spun around a lot, this Ring camera offers a lot of adaptabilities – in fact, when it’s initially received, the camera is upside down in the box:
In the box, a ring floodlight cam shows how the light and cam are angled.
When the ball mount on the Ring Floodlight Cam is loosened, it travels freely.
However, there are several drawbacks, such as the risk of water entry if the camera is mounted fully upside down and getting the camera facing in the appropriate direction (which may need a warranty-breaking DIY hack!). Before we get into some details, let’s have a look at a few alternative surfaces to which this light can be linked.
How to Mount a Ring Floodlight on Eaves?
This light can be mounted on soffits, eaves, and awnings, among other places. The difficulty arises from ensuring that you’ve chosen an appropriate place and making a few issues to consider:
- Make sure you’ve chosen a dry spot first. When it rains, some of these surfaces may become wet, resulting in a damaged or broken floodlight. After that, you’ll want to choose a site that has the necessary wiring.
- Wiring was not considered when most soffits and eaves were installed. As a result, you’ll almost certainly need to hire an electrician to install a connection to your desired site. This could be a convenient and inexpensive work or a bit of a pain, depending on the difficulty of the job and the market in your area.
Thankfully, this is intended to be feasible, and the Floodlight Cam Plus handbook details how to do so:
The Ring Floodlight Camera Plus user handbook, which shows the eaves mount option.
Just make sure you use all of the rubber grommets to keep water out:
Option to install on the eaves Ensure that the waterproofing grommets that included with the kit are installed.
Mounting on the Ceiling
The obstacles of placing a Ring floodlight on the ceiling are similar to those of mounting it on a soffit or eave, but there are a few additional issues to consider.
The most serious problem here is weight. Although the Ring Floodlight Camera isn’t particularly hefty (it weighs roughly four lb/1.8kg), you should nevertheless double-check your mounting site. This necessitates selecting the appropriate mounting hardware. It’s possible that your ceiling is comprised of drywall. In this situation, drywall anchors will be required to ensure that the camera does not become loose over time.
Ceilings do have the benefit of better wiring. If you have a lighting fixture that you are prepared to give up, it most certainly has the necessary wiring for this camera.
The Biggest Challenge – Getting the Camera Angle Right
The camera angle is the most difficult aspect of unusual Ring floodlight mountings.
You will face a considerable reduction in your field of view if the camera or PIR sensor has shallow angles as a result of having the entire unit upside down or on an angle.
There are two hacks that will restore the sensor’s full range of standards. The first is a speedier, easier option that provides less flexibility. The second option we’ll consider is a more powerful one that will include some physical modifications to your Ring Floodlight Camera.
An Easy Hack for Mounting the Ring Floodlight
This ‘quick hack’ won’t offer your camera (or its motion detectors) a lot of range, but it also won’t require you to grind away a piece of your Ring camera (which we’ll look at later…).
It all comes down to your smart home system’s objectives.
To begin, make sure the wires leading to the camera have enough slack to allow you to move it around freely.
You’ll also want to remove the screw that holds this ball socket together:
When the screw is tightened, the ball mount on the Ring Floodlight Cam slides freely.
Afterward, when just rotate the cam housing 180 degrees, insert it back into the socket, and secure the screw.
This will produce the opposite of the standard camera viewpoint. This enables you to maximize mounting on eaves, awnings, and ceilings without damaging the camera’s casing. If you reset the Ring floodlight camera before sending it in for repairs, you can keep your warranty valid. If you don’t want to tell Ring, we won’t!
However, because the camera unit is very heavy, make sure you hold it with your hand when maintaining its balance in the ball mount – otherwise, the camera will rest totally on the electrical line (and hence potentially fall to the ground), particularly if there’s a slack connection anywhere inside the main body):
The electrical cable is exposed because the Ring Floodlight Cam is loose in its ball mount.
Conversely, if your mounting location necessitates greater flexibility, there is a ‘better solution – although one that may void your warranty.
Hacking Your Ring Floodlight Camera the Hard Way
This is a really effective ruse. Your warranty will almost probably be void if you take this route. The good news is that it’s also a fantastic tool to fine-tune your camera shots for any mounting site.
We’ll make some physical changes to the ball joint that the camera connects to in order to complete this hack.
Now, here’s a swift video tutorial from YouTube. If you want more detailed instructions, go to:
To begin, loosen the screw that holds the ball socket together. This will enable you to disconnect the camera from the socket for a short period of time. The screw is held in place by a tiny nut. Take care not to misplace it. You’ll also want to ensure sure the wire has enough slack to allow the camera to move out of the socket.
The following stage necessitates the use of some equipment.
This job can be completed with a Dremel or any other form of small grinding, saw, or chopping instrument.
Just grind away a portion of the plastic to make a u-shaped recess on the opposite side of the one formed by the factory. The idea is to effectively reproduce the same joint, but in reverse, so that we can flip the camera.
After you’ve finished your recess, replace the camera in the socket, tighten the screws, and tip the camera backward. This one will provide you with a greater range of motion for your rapidly increasing requirements.
Keep This in Mind When Trying Out These Mounting Options
When it comes to placing a Ring floodlight camera in unique ways, there are a few things to keep in mind.
The Ring Floodlight Camera Warranty
The Ring Floodlight Cam comes with a one-year warranty. The very 1st thing to bear in mind is that both of our hacks for adjusting the angle of the camera may void your warranty.
While the simple hack may be undone quickly, it could still be considered a modification that violates the warranty’s restrictions. The other hack, on the other hand, clearly modifies the gadget permanently and breaks the manufacturer’s warranty. If you intend to rely on the guarantee for the entire year or for the duration of your Ring Protect Plus plan, you may wish to consider different mounting options. Either that or deal with the angles that aren’t ideal. The elements are also something to consider.
Keeping Your Ring Floodlight Camera Dry
The Best Ways to Keep Your Ring Floodlight Camera Dry is given below-
- The Ring Floodlight is intended to be installed on a vertical surface, right hand side up.
- This installation provides the best weather and, in particular, water damage protection.
- Water could enter the unit if the mounting location is changed, causing catastrophic damage.
- Consider the path water travels when running down your roof if you’re installing something on an eave or soffit.
These overhangs are excellent at diverting water away from your walls and foundations, but that doesn’t mean they don’t leak or get wet. If the water is going to run straight into the Ring Floodlight Cam mounting, you will need to safeguard yourself from this, which may entail:
- If necessary, reposition the Floodlight Cam.
- To make it waterproof, apply silicone sealant…
- …or a different waterproofing substance (such as specialized particular tape).
Another important consideration is wiring.
Powering Your Floodlight Cam
These Ring cameras are not self-contained systems.
These, unlike smaller smart cameras and lights, require a physical connection to your building to stay charged up.
Therefore, it means that in order to connect these lights properly, you may need to attach wiring to your overhand, ceiling, or another area.
This may necessitate hiring an electrician, depending on the site you choose.
Keep all these guidelines in mind, and then you will be able to put down your Ring floodlight camera and do whatever you want!
